Quick Details

  • Type: Clear Quartz Plate
  • Application: HEATING/DRYING, high temperature window of war industry, laser, metallurgy , optical
  • Thickness: 0.25-30MM
  • Shape: Circular Shape
  • Place of Origin: Jiangsu, China (Mainland), Jiangsu, China
  • Brand Name: RESUCERIAL
  • Model Number: RE327
  • Product name: Quartz glass plate quartz disc quartz wafer 0.25mm
  • name: quartz plate
  • Softening Point: 1680℃
  • Annealing Point: 1210℃
  • Density: 2.2g/cm3
  • Thermal Conductivity(20℃): 1.40W/m.℃
  • Specific Heat(20℃): 670J/Kg.℃
  • Glass Type: High purity, with or without coated, clear or translucent

Packaging & Delivery

Packaging Details Quartz glass plate quartz disc quartz wafer 0.25mm of package:
1pcs sperate pack+ carbon case+ plywood case

Quartz glass plate quartz disc quartz wafer 0.25mm



The optical quality of quartz glass has the originality, it both may penetrate the extreme ultraviolet, is the best of all ultraviolet materials, and may penetrate the ultraviolet and the near-infrared spectrum, the thermal-expansion coefficient minimum, the chemical stability is good, the air bubble, the stripe, the uniformity, the double refraction have may compare favorably with the general optical glass, therefore it is works originally in each kind of bad field,has the high stability optics coefficient and the essential optical material.



Mainly applies in the high temperature window of war industry, laser, metallurgy , optical instrument, stage light.







Quartz glass plate quartz disc quartz wafer 0.25mm

Product Description



Fused  Quartz glass plate quartz disc quartz wafer 0.25mm   :

1.The optical quality of quartz glass has the originality, it both may penetrate the extreme ultraviolet.

2.Is the best of all ultraviolet materials, and may penetrate the ultraviolet and the near-infrared spectrum.

3.The thermal-expansion coefficient minimum.

4.The chemical stability is good, the air bubble, the stripe, the uniformity, the double refraction have may compare favorably with the general optical glass.

5.Therefore it is works originally in each kind of bad field,has the high stability optics coefficient and the essential optical material.

6.Mainly applies in the high temperature window of war industry, laser, metallurgy , optical instrument, stage light.



Parameter of  Quartz glass plate quartz disc quartz wafer 0.25mm:

ModelRE209
BrandResucerial
SizeRectangle<1000x1000mm,round <1000mm
MaterialHigh purity >99.95%(SiO2)
Wall Thickness0.30-20mm
Broken Through Strength 20℃ DC 25-40kv/mm, 500℃ DC 4-5kv/mm
Electric Resistance 400℃ 108/m,800℃ 6.3x10/m
Softening Point1680℃
Annealing Point1210℃
Strain Point1120℃
Density2.2g/cm
Hardness5.5-6.50Mohs'
Design Tensile Strength4.80x10N/m^2
Design Compressive Strength1.10x109 N/m^2
Cofficient Of Thermal Expansion(20-320℃)5.70x10-7 cm/cm.℃
Thermal Conductivity(20℃)1.40W/m.℃
Specific Heat(20℃)670J/Kg.℃
Electrical Resistivity(350℃)7x107ohm.cm
Dielectric Constant3.75
Dielectric Strength5x107 V/m
Typical ApplicationWindows,Heat shield,secondictor,optical and etc
